| const std::string & | getName () const |
| | Return the object name. More...
|
| |
| virtual bool | getIsInitialized () const |
| | Return whether the operator is initialized. More...
|
| |
| virtual void | setHomogeneousBc (bool homogeneous_bc) |
| | Set whether the operator should use homogeneous boundary conditions. More...
|
| |
| virtual bool | getHomogeneousBc () const |
| | Return whether the operator is using homogeneous boundary conditions. More...
|
| |
| virtual void | setSolutionTime (double solution_time) |
| | Set the time at which the solution is to be evaluated. More...
|
| |
| virtual double | getSolutionTime () const |
| | Get the time at which the solution is being evaluated. More...
|
| |
| virtual void | setTimeInterval (double current_time, double new_time) |
| | Set the current time interval. More...
|
| |
| virtual std::pair< double, double > | getTimeInterval () const |
| | Get the current time interval. More...
|
| |
| virtual double | getDt () const |
| | Get the current time step size. More...
|
| |
| virtual void | setHierarchyMathOps (SAMRAI::tbox::Pointer< HierarchyMathOps > hier_math_ops) |
| | Set the HierarchyMathOps object used by the operator. More...
|
| |
| virtual SAMRAI::tbox::Pointer< HierarchyMathOps > | getHierarchyMathOps () const |
| | Get the HierarchyMathOps object used by the operator. More...
|
| |
| virtual void | apply (SAMRAI::solv::SAMRAIVectorReal< NDIM, double > &x, SAMRAI::solv::SAMRAIVectorReal< NDIM, double > &y)=0 |
| | Compute \(y=F[x]\). More...
|
| |
| virtual void | applyAdd (SAMRAI::solv::SAMRAIVectorReal< NDIM, double > &x, SAMRAI::solv::SAMRAIVectorReal< NDIM, double > &y, SAMRAI::solv::SAMRAIVectorReal< NDIM, double > &z) |
| | Compute \(z=F[x]+y\). More...
|
| |
| virtual void | initializeOperatorState (const SAMRAI::solv::SAMRAIVectorReal< NDIM, double > &in, const SAMRAI::solv::SAMRAIVectorReal< NDIM, double > &out) |
| | Compute hierarchy dependent data required for computing y=F[x] and z=F[x]+y. More...
|
| |
| virtual void | deallocateOperatorState () |
| | Remove all hierarchy dependent data allocated by initializeOperatorState(). More...
|
| |
| virtual void | modifyRhsForBcs (SAMRAI::solv::SAMRAIVectorReal< NDIM, double > &y) |
| | Modify the RHS vector to account for boundary conditions. More...
|
| |
| virtual void | imposeSolBcs (SAMRAI::solv::SAMRAIVectorReal< NDIM, double > &u) |
| | Impose boudary conditions in the solution vector. More...
|
| |
Before calling apply(), the form of the vectors x and y should be set properly by the user on all patch interiors on the specified range of levels in the patch hierarchy. The user is responsible for all data management for the quantities associated with the vectors. In particular, patch data in these vectors must be allocated prior to calling this method.
- Parameters
-
| x | input vector |
| y | output vector, i.e., \(y=F[x]\) |
Conditions on Parameters:
- vectors x and y must have same hierarchy
- vectors x and y must have same structure, depth, etc.
In general, the vectors x and y cannot be the same.
- Note
- Subclasses may require that the operator be initialized prior to calling apply().
- See also
- initializeOperatorState
Implemented in IBTK::PETScSNESJacobianJOWrapper, IBTK::PETScMFFDJacobianOperator, IBTK::PETScSNESFunctionGOWrapper, IBAMR::ConvectiveOperator, IBAMR::VCStaggeredStokesOperator, IBTK::PETScMatLOWrapper, IBTK::SCLaplaceOperator, IBTK::CCLaplaceOperator, and IBTK::VCSCViscousOperator.
Before calling applyAdd(), the form of the vectors x, y, and z should be set properly by the user on all patch interiors on the specified range of levels in the patch hierarchy. The user is responsible for all data management for the quantities associated with the vectors. In particular, patch data in these vectors must be allocated prior to calling this method.
- Parameters
-
| x | input vector |
| y | input vector |
| z | output vector, i.e., \(z=F[x]+y\) |
Conditions on Parameters:
- vectors x, y, and z must have same hierarchy
- vectors x, y, and z must have same structure, depth, etc.
In general, the vectors x and y cannot be the same.
- Note
- Subclasses may require that the operator be initialized prior to calling applyAdd().
- See also
- initializeOperatorState
- Note
- A default implementation is provided which employs apply() and SAMRAI::solv::SAMRAIVectorReal::add().
Reimplemented in IBTK::PETScSNESJacobianJOWrapper, and IBTK::PETScMatLOWrapper.
The vector arguments for apply(), applyAdd(), etc, need not match those for initializeOperatorState(). However, there must be a certain degree of similarity, including
- hierarchy configuration (hierarchy pointer and level range)
- number, type and alignment of vector component data
- ghost cell widths of data in the input and output vectors
- Note
- It is generally necessary to reinitialize the operator state when the hierarchy configuration changes.
It is safe to call initializeOperatorState() when the state is already initialized. In this case, the operator state is first deallocated and then reinitialized.
Conditions on arguments:
- input and output vectors must have same hierarchy
- input and output vectors must have same structure, depth, etc.
Call deallocateOperatorState() to remove any data allocated by this method.
- See also
- deallocateOperatorState
- Parameters
-
| in | input vector |
| out | output vector |
Reimplemented in IBTK::PETScSNESJacobianJOWrapper, IBAMR::AdvDiffWavePropConvectiveOperator, IBTK::PETScMatLOWrapper, IBTK::PETScMFFDJacobianOperator, IBTK::PETScSNESFunctionGOWrapper, IBAMR::INSCollocatedPPMConvectiveOperator, IBAMR::CellConvectiveOperator, IBAMR::INSStaggeredCUIConvectiveOperator, IBAMR::INSCollocatedCenteredConvectiveOperator, IBAMR::INSStaggeredWavePropConvectiveOperator, IBAMR::INSStaggeredStabilizedPPMConvectiveOperator, IBAMR::INSCollocatedWavePropConvectiveOperator, IBAMR::INSStaggeredPPMConvectiveOperator, IBAMR::INSStaggeredCenteredConvectiveOperator, IBAMR::INSStaggeredUpwindConvectiveOperator, IBAMR::CFUpperConvectiveOperator, IBTK::SCLaplaceOperator, IBTK::CCLaplaceOperator, IBTK::VCSCViscousOperator, and IBAMR::CIBStaggeredStokesOperator.
